Internet

Compatible with any connection
You can use your FRITZ!Box with any DSL- and IP-based connection. Alternatively, you can run it behind a fiber optic or cable modem and simply integrate it into an existing Wi-Fi network. It can even be operated with a 4G/3G dongle.


At home anywhere with MyFRITZ!
With MyFRITZ! from AVM, benefit from secure and convenient access to your FRITZ!Box from anywhere in the world. Retrieve files stored in FRITZ!NAS, view your recent call list and listen to messages left on your answering machine. With MyFRITZ!App, you can even access your FRITZ!Box remotely using your smartphone or tablet.


Peace of mind
FRITZ!Box offers comprehensive protection against attacks. The preconfigured firewall, filter function, and DECT and Wi-Fi encryption ensure secure connections. Parental controls and guest Internet access are, of course, included free of charge.


Encrypted communication via VPN
Thanks to the recognized industry standard IPsec, you can establish a virtual private network to connect with your FRITZ!Box or company network. The settings can be configured on your FRITZ!Box and transferred to smartphones, tablets, and computers.


Ready for the future with IPv6
In addition to IPv4, FRITZ!Box supports the IPv6 Internet protocol. IPv6 makes existing services more convenient and simplifies a host of new applications, so you can rest assured that you’re ready for the latest technologies.


Mesh Wi-Fi with FRITZ!
With FRITZ! your Wi-Fi grows to whatever size you need at the touch of a button. Combine FRITZ!Box with the intelligent FRITZ!Repeaters and FRITZ!Powerline to adjust your home network to your individual needs and enjoy full Mesh convenience with FRITZ!.


Wi-Fi 6
The new Wi-Fi 6 offers extremely fast and reliable connection options. It's designed to enable reliable and fast transmission rates even when multiple end devices are being used at the same time.


Wi-Fi guest access
Offer your guests simple Internet access. The guest access has its own network key and name. It's possible establish a welcome page for customers in cafés or guests at home. Visitors have no access to the home network, so your data stays private.


FRITZ!Box as a private hotspot
When using your FRITZ!Box as a hotspot, you can restrict Internet usage to surfing and e-mail. You have a usage log, while your guests benefit from an integrated QR code that makes it easy for them to connect to the Internet.


Complete Wi-Fi control
Wi-Fi on or off? You can either leave it completely to the automated Wi-Fi night service or take care of it yourself using the “WLAN” button on your FRITZ!Box. Alternatively, you can use FRITZ!Fon as a convenient remote control.


Secure ex works
Every FRITZ!Box is delivered with its own network key to protect your network from unauthorized access. All Wi-Fi networks including guest access can be secured with their own unique key.


Connected in no time
Thanks to WPS (Wi-Fi Protected Setup) you can connect your wireless devices in no time. Simply push the connecting WPS button on both devices for safe, automatic registration.

Complete connectivity
The FRITZ!Box is compatible with all common telephones — analog phones, fax machines, IP and ISDN telephones, and telephone systems. Any devices connected can easily be managed with user-friendly menus.


Cordless freedom with DECT
Up to six cordless telephones can be registered on the integrated DECT base station, with all conversations securely encrypted upon delivery. FRITZ!Box uses the DECT standard, offers additional convenience features when used together with a FRITZ!Fon.


Answering machine with voice to mail
Once activated, the built-in answering machine stores voice messages and sends them to you by email, giving you the opportunity to call back if necessary. The answering machine can also be set to switch on and off at certain times.


All contacts synchronized
You can either save your telephone book contacts on the FRITZ!Box or use existing Google contacts. The FRITZ!Box synchronizes the entries automatically so that you’re always up to date.


Send and receive faxes
The FRITZ!Box's fax function eliminates the need for external fax machines. In the user-friendly menu you can insert text and attach an image. Incoming faxes will be forwarded to your email address as a PDF.


Making perfect HD telephone calls
Enjoy top-quality phone calls. Thanks to cutting-edge technology, voices sound as clear and precise as if the other caller were sitting in the same room. Both FRITZ!Box and FRITZ!Fon support HD telephony ex works.

fritz.box – everything made easy
FRITZ!OS is the FRITZ!Box operating system and can be easily controlled via your browser. User-friendly menus, easy-to-understand wizards, and the optional advanced mode come in handy in all scenarios.


Free updates
FRITZ!OS undergoes constant development for even more convenience and performance. The latest developments are available for to download for free, either manually or via auto-update. This way, your FRITZ!Box is always up to date.


Media server for great entertainment
The FRITZ!Box manages all connected USB storage devices and makes their contents available throughout the network. The media server lets users enjoy music, photos, and videos on network-enabled playback devices.


FRITZ!Apps for iOS and Android
The practical FRITZ!Apps offer a wealth of exciting features for smartphones and tablets. Use these free apps for increased convenience when you’re on the go.


Smart Home: the clever place to live
Conveniently control Smart Home devices with FRITZ!OS. Operate connected devices with FRITZ!DECT 200 or adjust room temperature with FRITZ!DECT 301. FRITZ! DECT 500 provides dimmable and color lighting, while the FRITZ!DECT 440 four-way smart switch is the ideal remote control.


Maximum energy efficiency
The many features offered by FRITZ!OS remove the need for additional devices such as fax and answering machines. And with DECT and Wi-Fi transmission power reduced when the features are not in use, you save both energy and money.


Support for DECT ULE/HAN FUN
DECT ULE/HAN FUN is a manufacturer-independent standard for Smart Home devices. DECT ULE/HAN FUN is included in the FRITZ!Box upon delivery, making it possible to integrate third party Smart Home devices in the home network e.g. wall switches, motion sensors and door-window contacts.

Width 200 mm, Depth 152 mm, Height 45 mm,Weight 750 g

Interfaces
VDSL or ADSL line
IP-based telephony
4 x gigabit LAN, WAN via LAN 1 port
Wireless access point compliant with IEEE 802.11ax, ac, n, g, a
1 x USB port for printers and storage media
Integrated DECT base station for up to six cordless telephones
1 a/b port (either TAE or RJ11) for an analog telephone, answering machine or fax

Internet
DSL router with firewall/NAT, DHCP server, DynDNS client, UPnP AV
VDSL or ADSL line
Supports VDSL connections up to 300 Mbit/s with supervectoring (35b)
Supports VDSL lines with 100 Mbit/s with vectoring (full vectoring)
Supports VDSL Long Reach
Use of existing Internet connections via LAN
Router operation with a cable modem, fiber optic connection or 3G data dongle (LTE/UMTS/HSPA)
Supports IPv6
Stateful Packet Inspection Firewall with port sharing
Secure remote access over the internet with VPN (IPSec)

Wi-Fi
Wi-Fi 6 up to 1800 Mbit/s (5 GHz) and 600 Mbit/s (2.4 GHz)
Compatible with the IEEE 802.11a/g/n/ac wireless standards
Extends your home network with Mesh Wi-Fi – simply combine two or more wireless access points into one intelligent system.
2 x 2 (2.4 GHz), 3 x 3 (5 GHz) with MU-MIMO
Dual-band Wi-Fi: Concurrent use of the 5-GHz and 2.4-GHz bands
Secure upon delivery with WPA2 encryption; WPA3 is also available
AVM Stick & Surf: automatic security for cable-free surfing
WLAN button (switch Wi-Fi on/off manually)
Wi-Fi Protected Setup (WPS)
Wi-Fi guest access – secure surfing for friends and visitors
Wi-Fi auto channel: Automated search for Wi-Fi channel free of interference
Wi-Fi Eco for optimum performance at minimum power consumption

Telephony
Telephone system for IP-based connections
Integrated DECT base station for up to six cordless telephones
Voice transmission encrypted upon delivery
1 a/b port (either TAE or RJ11) for an analog telephone, answering machine or fax
Supports HD telephony for natural sound
DECT Eco: Frequency channel switches off for maximum ergonomics
Five integrated answering machines including email forwarding (voice-to-mail)
Fax function including email forwarding (fax-to-mail)
Manage telephone contacts locally or online (Google, Apple iCloud etc.)
Call lists, number blocking, quick-dial numbers, extensions
Dialing rules for tailoring use of specific numbers
Call diversion, internal calls, three-way conferencing, call transfer
Call blocking, alarm, baby monitor, VIP calls and Do not Disturb
Internet telephony SIP-compliant in accordance with RFC 3261
Registration of IP telephones (LAN/Wi-Fi) SIP-compliant
FRITZ!App Fon for landline calls via your smartphone

Home network convenience
Media server makes music, pictures and movies available to devices in the home network (DLNA/UPnP AV)
Secure access to your own FRITZ!Box from anywhere with MyFRITZ!
FRITZ!NAS – simple, browser-based access to all files in the network ; can be shared with friends and family
Networked applications such as Internet TV, video on demand and streaming
Parental controls, push service, cloud contacts
Guest access: share your internet connection over LAN or Wi-Fi
Wake on LAN over the Internet
Supports devices compliant with DLNA
Also supports online storage, web radio and podcasts

FRITZ!OS
"fritz.box": multi-language user interface, for intuitive operation via Web browser
User interface optimized for smartphones and tablets (responsive design)
Free updates for new functions and security
Advanced view for special configuration options, help function with full-text search
Handy FRITZ!Apps for your smartphone: MyFRITZ!App for FRITZ! convenience on the go, the clever Wi-Fi helper FRITZ!App WLAN and FRITZ!App Smart Home for intuitive control of your FRITZ! Smart Home
Smart Home features integrated in the user interface
Smart Home support for DECT ULE/HAN FUN devices
Smart Home devices can be switched manually and automatically both in the home network and from the Internet


Package contents
FRITZ!Box 7530 AX
Power adapter
4-meter long DSL connecting cable
1.5 meter-long LAN cable
Quick guide

Device properties
Dimensions (W x H x D): 200 x 45 x 152 mm
Can be wall mounted

Average power consumption: 6 watts


Warranty
5-year manufacturer’s warranty for end customers, as per the warranty conditions
