Key Features
Forty-eight (48) 2.5GbE 802.3af/at PoE+ RJ45 Ports.
Four (4) 10GbE SFP+ Ports.
USP RPS Support for Redundant Power Backup (sold separately).
720W Maximum PoE Power.
1.3-inch Touch LCM with AR Switch Management.
Managed with UniFi Network Application and Mobile app.
Works with UniFi Network Application
Manage Your Networks from a Single Control Plane
Intuitive and Robust Configuration, Control and Monitoring
Remote Firmware Upgrade
Users and Guests
Guest Portal/Hotspot Support

Width 442 mm, Depth 400 mm, Height 44 mm,Weight 7 kg

Mechanical
Dimensions 442 x 400 x 44 mm (17.4 x 15.7 x 1.7")
Weight Without mounting brackets: 6.2 kg (13.7 lb)
With mounting brackets: 6.3 kg (13.9 lb)
Enclosure material SGCC steel
Hardware
Management interface Ethernet In-Band
Networking interface (48) 2.5 GbE RJ45 ports
(4) 1/10G SFP+ ports
PoE interface (48) PoE/PoE+ (Pins 1, 2+; 3, 6-)
Total non-blocking throughput 160 Gbps
Switching capacity 320 Gbps
Forwarding rate 238.095 Mpps
Power method (1) Universal input, 100—240V AC, 10A Max., 50/60 Hz
(1) USP-RPS DC input, 52V DC, 13.84A; 11.5V DC, 13A
Power supply AC/DC, internal, 100—240V, 10A Max.
Supported voltage range 100—240V AC
Max. power consumption 150W (Excluding PoE output)
Total available PoE 720W
Max. PoE wattage per port by PSE PoE+: 34.2W
Voltage range PoE mode PoE: 44—57V
PoE+: 50—57V
Services SMB Layer 3 PoE GbE Switch
ESD/EMP protection Air: ± 16kV, contact: ± 12kV
LCM display (1) 1.3" color touchscreen
Button Factory reset
Ambient operating temperature -5 to 40° C (23 to 104° F)
Ambient operating humidity 10 to 90% noncondensing
Certifications CE, FCC, IC
Switching Features
Layer 2 features IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
Layer 3 features DHCP for locally-managed networks
DHCP relay
Inter-VLAN routing between networks on same switch
Static routing between local networks
Network isolation with ACLs
LEDs
System Status
Ethernet Link/activity
SFP+ Link/activity
Application Requirements
UniFi Network Version 6.2.26 and later
